SYSTEM GEAR OIL VG SERIES

SYSTEM GEAR OIL VG SERIES

SYSTEM GEAR OIL VG SERIES is EP (Extreme pressure) gear oil. It is formulated with mineral base oils and additive packets, specially developed for gear systems operating under heavy loads. It is recommended for use in all industrial closed gear systems.

FEATURES AND BENEFITS

  • High performance against wear and friction
  • High resistance to oxidation
  • Superior protection against rust and corrosion
  • Low tendency to foam

THE MEET SPECIFICATIONS AND APPROVALS

DIN 51517 PART 3, ISO 12925-1 CKD, AGMA 9005-D94 EP, CINCINNATI MILACRON, DAVID BROWN, AISI 224, SEB 181226

TYPICAL PROPERTIES

TEST UNIT METOD 68 100 150 220 320 460
Density,@ 15 ⁰C g/cm 3 ASTM D 4052 0,882 0,887 0,892 0,898 0,902 0,908
K. Viscosity,@ 40 ⁰C cSt ASTM D 445 61,2- 74,8 90-110 135-165 198-242 288-352 414-506
Viscosity Index   ASTM D 2270 98 95 95 95 93 93
Flash Point ⁰C ASTM D 92 220 226 238 248 250 254
Pour Point ⁰C ASTM D 97 -24 -22 -12 -9 -9 -9

* The above values may vary slightly according to production.
